Rubber Track Undercarriage for drill rig

We are specialized in manufacturing Rubber Track Undercarriage for drill rig. We make custom rubber track undercarriage for your mobility needs, and our rubber track undercarriage can carry up to 50ton, and supporting dual-speed final drive and travel 0-7km/h at grades up to 60%.

Send Inquiry

Product Description

Product introduction:

Our subsidiary company, Bonny tracked undercarriage factory, is specialized in the research and development of Rubber Track Undercarriage for drill rig. Since the establishment of Bonny, it keeps the whole world in view and blaze steadily new trails. By now, we have developed various Drilling Rig Rubber Track Undercarriage and the load capacity is from 0.5 ton to 30 ton. Meanwhile, we have a lot of experience engineers who can provide you technical support and technical consultancy to meet your needs.


Application of rubber track undercarriage:

Drilling machine: Anchor drilling rig, water well drilling rig, core drillingrig, Jet drilling rig, down-hole
drilling rig, hydraulic crawler drilling rig,, for poling rig, multipurpose drilling rig, no-dig drilling rig, etc.
Construction machinery machine: mini excavator, mini pilling machine, Aerial work platform, Small
transport loading equipment, etc.
Coaling machine: slag-raking machine, tunnel drilling rig, hydraulic drilling machine, rock loader, etc
Mining machine: mobile crusher, heading machine, conveying equipment, etc.
Agriculture machine: Sugar cane harvester, lawn mower, compost turner, ditching machine, etc


Features of Drilling Rig Rubber Track Undercarriage:

1.Adopt high strength engineering rubber track.
2.The track motor of rubber track undercarriage can be fixed displacement or variable displacement concealed planetary gearbox and hydraulic motor. If you need, we can also provide track motor made by our own factory.
3.The beam of rubber track undercarriage is made of Q345B with high loading capacity.
4.It can also be designed and manufactured on customers' request for the rubber track undercarriage.


Technical parameters:

MODEL

Dinamic  capacity

Static  capacity

Weight kg.

Press.Bar

oil flow L/min

Torque Nm to engine

Grad.

Speed km/h

RT-1500

1200

1500

330

270

17

2000

65%

1.7

RT-2500

2500

3000

380

220

35

4723

65%

2/3.2

RT-3500

3500

4000

650

220

35

4723

65%

2/3.5

RT-5000

5000

6000

900

220

55

8330

65%

2/3.7

RT-6000

6000

7000

1280

220

55

8330

65%

2/3.7

RT-8000

8000

9500

1550

300

82

11700

65%

2.8/4.7



MODEL

A Length

B Center Distance

C Height

D Total Width

E Width of track shoe

F Height of Cross beam

No. of  roller

RT-1500

1420

1066

350

980

230

165

3+3

RT-2500

1850

1370

480

1220

250

245

4+4

RT-3500

1980

1511

500

1520

300

250

5+5

RT-5000

2500

1950

550

1800

350

265

6+6

RT-6000

2905

2355

550

1800

400

265

7+7

RT-8000

2950

2450

600

1800

400

310

7+7


Type of track drive gearbox


Application of rubber track undercarriage


FAQ

1. Are you the manufacturer or trader of crawler undercarriage?
We are the manufacturer with more than 20 years experience engaged in designing and manufacturing of rubber crawler track undercarriage.
2. How long is the delivery?
Usually it is 25 days for the production.
3. What's the warranty of your product?
We can offer you 12 months quality guarantee period after receipt of product.
4. Can you custom make the product?
Yes, all dimensions and specifications of rubber crawler track undercarriage can be designed and made based on your requirements.
5. How to order?
To make sure the offered rubber crawler undercarriage is suitable for your application, please offer the following details:
1. Rubber or steel track undercarriage:
2. What is the payload of undercarriage:
Note: it is the weight of machine excluding the weight of undercarriage.
3. length of track undercarriage (mm):
4. width of each side of track undercarriage (mm):
5. height of track undercarriage (mm):
6. total width of track undercarriage (mm):
7. working flow rate per each side of undercarriage (L/min):
8. working pressure (MPa):
9. travelling speed (km/hr):
10. climbing capacity:
